[Discontinued] ST896 3.5" LCD Monitor CCTV Security Tester Camera Video PTZ Audio UTP Test

Description:
The CCTV testerPro  STest-896 is developed for the On-Site installation and maintenance of video monitoring system. It can be used for displaying video, testing video level, controlling PTZ, scanning PTZ address,  generating images, capturing data of RS485 and testing LAN cable etc. Its functions, easy operation, and portability makes it simple for the CCTV technician to install and maintain CCTV system, improving work efficiency and get the labor cost down.   STest-896 equipped with the Optical Power Meter. Use in testing the laser power of Video Fiber Optic Transmission equipment, and testing the Fiber Optic Patch Cord , etc.

STest-896 is an ideal multifunction Instrument for CCTV security system, Fiber Optical communication, CATV and other Fiber Optic works.

Features:
    3.5"TFT-LCD , 960(H)Ãâ€?40(V) resolution
    Optical power meter, testing the laser power of Video Fiber Optic Transmission equipment, and testing the Fiber Optic Patch Cord , etc.
    DC12V power output
    Audio input
    Adjustable brightness, contrast, color of LCD
    Video Level testing, video signals measured in IRE or mV
    Automatically identify and adapt the video mode of NTSC and PAL
    Colorbar Video signal generator, transmit/receive colorful images
    Support more than twenty kinds of PTZ controller protocols. For example, PELCO-P, PELCO-D, SAMSUNG etc.
    PPTZ address scanning, search up the ID of PTZ camera.
    Capture the PTZ protocol to assist the setting personnel to find out the control protocol and therefore easily target the problematic equipment.
    Support RS232 and RS485 interface, the rate 150-19200bps
    Powerful in testing LAN cable, measuring the connecting status and displaying the sequence of connection
    PTZ(P/L & Zoom) Control: Control the status of P/L, zoom in/out the camera, adjust the aperture, foci and setting parameters, run and call the preset.
    Lithium Ion Polymer Batteries(3.7V DC3000mAh), more reliable, and work 15 hours
    Easy for use that the train is almost unnecessary

Specfication:

??
