[Discontinued] MQ-136 Gas Sensor Hydrogen
[Discontinued] MQ-136 Gas Sensor Hydrogen
- 101-60-123
Couldn't load pickup availability
![[Discontinued] MQ-136 Gas Sensor Hydrogen](http://www.sainsmart.com/cdn/shop/products/4_27.jpg?v=1499266691&width=1445)
![[Discontinued] MQ-136 Gas Sensor Hydrogen](http://www.sainsmart.com/cdn/shop/products/1_33.jpg?v=1499266691&width=1445)
![[Discontinued] MQ-136 Gas Sensor Hydrogen](http://www.sainsmart.com/cdn/shop/products/3_36.jpg?v=1499266691&width=1445)
![[Discontinued] MQ-136 Gas Sensor Hydrogen](http://www.sainsmart.com/cdn/shop/products/2_41.jpg?v=1499266691&width=1445)
DESCRIPTION
Senitive material of MQ136 gas sensor is SnO2, which with lower conductivity in clean air. When the target Hydrogen sulfide gas exist, the sensor’s conductivity is higher along with the Hydrogen sulfide concentration rising. Please use simple electric circuit, Convert change of conductivity to correspond output signal of gas concentration. MQ136 gas sensor has high sensitity to Hydrogen sulfide, Low sensitivity for other combustible gas. It is with low cost and suitable for different application.
FEATURE
- Good sensitivity to Hydrogen sulfide
- Long life and low cost
- Simple drive circuit
Application:
- Domestic Hydrogen sulfide detector
- Industrial Hydrogen sulfide detector
- Portable Hydrogen sulfide detector
SPECIFICATION
|
Model No. |
MQ136 |
||
|
Sensor Type |
Semiconductor |
||
|
Standard Encapsulation |
Bakelite (Black Bakelite) |
||
|
Detection Gas |
Hydrogen sulfide |
||
|
Concentration |
1-200ppm (Hydrogen sulfide) |
||
|
Circuit |
Loop Voltage |
Vc |
�4V DC |
|
Heater Voltage |
VH |
5.0V±0.2V AC or DC |
|
|
Load Resistance |
RL |
Adjustable |
|
|
Character |
Heater Resistance |
RH |
31Ω±3Ω(Room Tem.) |
|
Heater consumption |
PH |
�00mW |
|
|
Sensing Resistance |
Rs |
2KΩ-20KΩ(in 50ppm SO2 ) |
|
|
Sensitivity |
S |
Rs(in air)/Rs(50ppm NH3)� |
|
|
Slope |
α |
�.6(R100ppm/R50ppm H2S) |
|
|
Condition |
Tem. Humidity |
20?±2?;65%±5%RH |
|
|
Standard test circuit |
Vc:5.0V±0.1V; VH: 5.0V±0.1V |
||
|
Preheat time |
Over 48 hours |
WHAT'S IN THE PACKAGE
- 1x SainSmart MQ136 Gas Sensor Hydrogen Module
