[Discontinued] SainSmart UNO ATMEGA328P-PU ATMEGA8U2 Microcontroller For Arduino

[Discontinued] SainSmart UNO ATMEGA328P-PU ATMEGA8U2 Microcontroller For Arduino

SKU:  20-011-900-US-KS
Regular price $14.99
-Liquid error (snippets/price line 160): divided by 0 Regular price Sale price $14.99
Shipping calculated at checkout.
  • 20-011-900-US-KS
View full details

Description:

The Arduino Uno is a microcontroller board based on the ATmega328 (datasheet). It has 14 digital input/output pins (of which 6 can be used as PWM outputs), 6 analog inputs, a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started.

The Uno differs from all preceding boards in that it does not use the FTDI USB-to-serial driver chip. Instead, it features the Atmega8U2 programmed as a USB-to-serial converter. Revision 2 of the Uno board has a resistor pulling the 8U2 HWB line to ground, making it easier to put into DFU mode.

"Uno" means one in Italian and is named to mark the upcoming release of Arduino 1.0. The Uno and version 1.0 will be the reference versions of Arduino, moving forward. The Uno is the latest in a series of USB Arduino boards, and the reference model for the Arduino platform; for a comparison with previous versions, see the index of Arduino boards.



Summary:

Microcontroller ATmega328
Operating Voltage 5V
Input Voltage (recommended) 7-12V
Input Voltage (limits) 6-20V
Digital I/O Pins 14 (of which 6 provide PWM output)
Analog Input Pins 6
DC Current per I/O Pin 40 mA
DC Current for 3.3V Pin 50 mA
Flash Memory 32 KB (ATmega328) of which 0.5 KB used by bootloader
SRAM 2 KB (ATmega328)
EEPROM 1 KB (ATmega328)
Clock Speed 16?MHz



Schematic & Reference Design

EAGLE files: arduino-uno-reference-design.zip

Schematic: arduino-uno-schematic.pdf



Package list:

  • 1x SainSmart UNO
  • 1x USB Cable
