[Discontinued] Switching Power Supply 350W 36V 9.7A for Arduino CNC SainSmart CNC Router Kits

Description:

This professional 350W 24V 14.6A Switching CNC Power Supply can be widely used in Industrial Automation and CNC Stepper/Servo System.
115V and 230V can be chosed by switch. Powerful functions(eg. PWM control) and professional designs (Built-in big fan for cooling) ensure high efficiency and high reliability of the power supply. Low cost also makes it more acceptable for general usage.



Features:

• 24V DC 14.6A output
• AC input voltage range: 90~132V/180~264VAC
• 115V/230V AC selected by switch
• High efficiency low cost
• Forced air cooling by built-in DC fan
• Low output ripple and yawp
• Over current, over voltage, short circuit and overheat protections
• 215*115*50mm (L*W*H)
• Please don't connect wires with Power-On.
• Please make sure chosed correct Input Voltage 115V or 230V before Power-On.

Specification:

• Model:S-350-24
• DC Output:24V 14.6A
• Wave and Noise:150mVp-p
• Inlet Stability:±0.1%
• Load Stability:±0.3%
• Efficiency:85%
• Adjustable Range:20.8V~27.2V
• AC Input Voltage:90~132V/180~264VAC Slected by Switch
• AC Input Current:3.54A/115VAC 1.73A/230VAC
• Working Temperature:-10~50°C
• Safety Standards:GB4943, UL60950, EN60950
• EMC Standards:GB9254, 55022, Class A
• Weight:1.1kg

Package List:

• 1x Switching CNC Power Supply
